AS 3600 verification library

ConcreteKalc verification examples.

Verification examples for RKALC reinforced and prestressed concrete design applications. Each report documents the adopted inputs, assumptions, hand calculations and comparison results against the RKALC application output.

Open ConcreteKalc Back to Verification Library

Published reports

Concrete verification examples

Each card provides a concise overview. Open the full PDF for the complete engineering calculation and verification evidence.

CV-001 AS 3600 Pad footing Published

Reinforced concrete pad footing

An independently prepared design example is compared directly with the RKALC pad footing calculation for the same geometry, materials and applied actions.

Flexural design in the critical direction
Column bearing stress and reinforcement development
Punching shear at the critical perimeter
One-way shear assessment
Direct comparison with the RKALC application and print report

View Verification PDF Open ConcreteKalc

CV-002 AS 3600:2018 + A1 RC & PT beams Published

General Beam RC and PT sections

Three published examples compare General Beam section calculations with an AS 3600:2018 T-beam design example and two legacy textbook capacity examples. The report explains differences in code factors, steel areas and modelling assumptions.

CSI Example 001: T-beam flexural and support-shear reinforcement
Warner Example 7.12: prestressed beam moment capacity
Warner Example 7.5: doubly reinforced beam with elastic compression steel
Section figures, comparison results and interpretations
Manual input tables and expected results for users to reproduce

View Verification PDF Open General Beam

Grassroots verification campaign

Contribute a concrete verification example

Contact RKALC before commencing to agree the scope and comparison method. Approved contributors receive two weeks of complimentary RKALC access to complete an agreed reinforced concrete verification study.

Contact RKALC
